Model:
DS-PWA64-L-WE
Description:
TCP/IP, Wi-Fi, and GPRS network
New generation wireless protocol: Tri-X/Cam-X
Long RF transmission distance
Two-way communication with AES-128 encryption
Connects up to 64 wireless zones/outputs (including 48 PIRCAMs), 32 wireless keyfobs, 2 repeaters, 4 sounders(2 internal+2 external), 8 tag readers and keypads.
Supports up to 32 network users, including 1 installer, 1 administrator, and 30 normal users
Voice prompt
Configuration via Web client, mobile client, and Convergence Cloud
Hik-Connect and Hik-ProConnect configuration depends on the user access level
Pushes alarm notification via messages or phone calls
Views live videos from Hik-Connect
Alarm video clips via emails and APP
Supports LED indicator to indicates system status
4520 mAh lithium backup battery
SIA-DC09 protocol, and supports both Contact ID and SIA data format
Supports Hik-IP Receiver and Hik-IP Receiver Pro for ARC communication
Software features:
Diagnostics – via the APP or Web Supported
Installer –1
Installer APP for programming –Supported
Web server for maintenance (offline configuration) –Supported
Wi-Fi standard –Supported
Arm modes –Away/Stay
Firmware upgrade –APP/Web Portal
Admin –1
Wired network –Supported
Programming tools –Hik-Connect/Hik-ProConnect/Web Portal/ IVMS4200/ Convergence Cloud
Forced arming with open zones –Supported
Memory log stored –5000
User –30
User APP for operating –Supported
Voice prompt –Supported
Area –16
Automatic arm/disarm timers –Supported
Hardware features
RS232 output –Supported
SIM slot –Single
GPRS on board –Supported
Loudspeaker built in –Supported
Electrical characteristics
Battery type –Built in on board Battery Li
Power supply –Built in power supply
Operation temperature – -10 °C to +55 °C (The battery can not be charged at temperature lower than 10°C, please make sure the adapter is connected)
Battery life span –Up to 12 hours at normal temperature (The battery working time can be significantly reduced at low temperatures)
Wireless transmission
RF frequency –868 Mhz
Wireless security – Frequency Hoping 128 AES Encryption
Display
LEDs status –Arm/Disarm, Alarm, Tamper, Fault, Cloud, Power
General
Dimension -(WxHxD)170.0 mm (6.7″) × 170.0 (6.7″) mm × 38.6 mm (1.5″)
Shell material –Plastic
Color –White
Weight –557.5 g (19.7 oz)
Device management
Tag –32
PIR cam –Supported
Zones –64 (up to 48 PIRCAMs)
Keypad –8 (including tag reader)
Wireless sounder –4(2 internal+2 external)
Wireless repeater –2
Keyfob –32
Report method
ARC protocol –SIA DC09 (SIA level 2, Contact ID), ISUP, ISAPI (SDK)
Hik-IP Receiver & Hik-IP Receiver Pro (Sur-Gard & Ademco 685)
Supports video verification and remote control
